Manual Keppe Motor 1.6 – Working Principles


Get to know the technology or even assemble your own Keppe Motor from start to finish, now buy the Keppe Motor Manual in PDF.

Product Description

Check below the list of suggested parts to build the Keppe Motor – Working Principle:

Parts List
1) 2 pieces of 2×1 cm electrical cable duct 19 cm long.
2) 1 wood plate 15 cm long, 10 cm wide and 0.5cm thick.
3) 1 rectangular piece of wood 5 cm long, 1 cm wide and 0.5 cm thick.
4) 1 piece of PVC tube with internal diameter of 2 cm and 3.5 cm long.
5) 1 on/off switch.
6) 1 rectangular piece of Styrofoam (or wood) 4.5 cm long, 3 cm wide and 1.5 thick, with a 2.6 x 1.6 cm rectangular hole in the middle.
7) 1 neodymium magnet with diameter of 0.8 cm and 0.5 cm high.
8) 1 Reed switch for 3 Amps.
9) 1 rectangular piece of cardboard 8.5 cm long, 6.3 cm wide, with a 6×3 cm rectangular internal hole.
10) 1 rigid and straight metal shaft. Dimensions: length=12 cm, diameter=2 mm.
11) 2 equal square pieces of cardboard with 1.9 cm side.
12) 2 flexible blue (or black) wires for 1 Amp with an alligator clip in one end and a female spade terminal on the other end.
13) 1 rubber cylinder with diameter=1.5 cm and central hole of diameter=1 mm.
14) 2 ball bearings with flange. Dimensions: internal diameter=2 mm, external diameter=6 mm (without flange) and total diameter=8 mm (with flange).
15) 1 plastic support for the transformer. Dimensions: length=8.5 cm, width=6.2 cm and high=4.4 cm. Dimensions of the inner hole: length=5.6 cm and width=3.2cm.
16) 2 block ferrite magnets, magnetized perpendicular to the large faces. Dimensions: length=4 cm, width=2 cm and thickness=0.8 cm
17) 1 9V-Alcaline battery.
18) 2 male spade terminals.
19) 1 standard 9V battery connector with two female spade terminals.
20) 250g of enameled copper wire, AWG 28.
